SSDUpgrader

Company: Cisco
End-of-life announcement for SSDUpgrader
2274 downloads
App checksum
md5 : b07ddb25166d85629c06d2f10670219e

Details


SSD Firmware Upgrader
=====================

The purpose of this app is to allow user to upgrade SSD firmware on ACI switches
without requirement to upgrade the NXOS software. This is for bug ID CSCvx19640.


This app will:
- Check if node requires a SSD firmware update
- Upgrade SSD firmware as a fix for CSCvx19640 (TAC needs to provide root access)

Usage:
-----

1) In Settings tab:
Enter ssh admin password
Enter root token (provided by TAC)
Click the Save icon (it is a small icon above the word Connectivity)
Note: If a valid root token is not provided, user will not be able to upgrade.
admin password is required for checking if upgraded is needed

2) In Devices tab:
Select node(s) and click Check for upgrade

3) If Upgrade is required, select node(s) and select Upgrade

Notes:
-----
- Standby sup cannot be upgraded until it becomes the Active sup.
- When root token is provided, script will use smartctl to verify SSD version
- Cisco recommends all SSD firmware upgrades be performed in a maintenance window.
- If error condition 128 under Temperature_Celsius is displayed, user will
need to reboot the node and try again. If error condition 128 is still
displayed after a reboot, please contact TAC

Update History:
--------------

What's new in version 1.6.0
- Fixed app bug

What's new in version 1.5.0
- Added logic to detect SSD error condition 128 under Temperature_Celsius
- Fixed issue to work on 2.2(3r)

What's new in version 1.4.0 and 1.3.0
- Cosmetic changes.

What's new in version 1.2.0
- Fixed issue to work on 2.2(3t)
- Display power on hours and estimate how many hours left till bug

What's new in version 1.1.0
- Ability to check if standby sup needs to be upgraded
- reload is no longer required
